High-Elevation System — Liberty
The Challenge
The property sits above 4,000 feet elevation and is subject to extreme freeze-thaw cycling, heavy snow loads, and high wind exposure from multiple directions.
The remote location required all materials to be staged in advance and the installation completed within a narrow weather window before first snowfall.
Our Approach
The system design began with a structural review to confirm the roof framing could support the specified metal panel system under maximum snow load conditions.
We installed a 6-inch eave ice barrier, a vented ridge assembly, and interlocking concealed-fastener metal panels selected for corrosion resistance and long service life at high elevation.
All penetrations and transitions were detailed with high-temperature flashing tape and sealed with urethane sealant rated for prolonged UV and freeze-thaw exposure.
The Result
The completed system has performed through two full winter seasons without any reported leaks, ice dam formation, or fastener failures.
The metal panel system continues to shed snow effectively, reducing roof load accumulation and minimizing maintenance requirements for the property owner.
Key Elements
- Full ice and water shield coverage in vulnerable zones
- Balanced ridge and intake ventilation system
- Architectural composition shingles rated for high-wind and heavy weather exposure
- Reinforced flashing at low-pitch transitions
- Integrated underlayment system for moisture management
